Incoloy A-286 Coil Supplier
As a powerful Incoloy materials supplier, AEETHER produces and manufactures Incoloy A-286 coil of high quality and low price.
INCOLOY® alloy A-286 (UNS S66286 / W.Nr. 1.4980) is an iron-nickel-chromium alloy with additions of molybdenum and titanium. It is agehardenable for high mechanical properties. The alloy maintains good strength and oxidation resistance at temperatures up to about 1300°F (700°C). The alloy is austenitic in all metallurgical conditions.
Incoloy A-286 coil is a nickel alloy raw material manufactured by rolling up a Incoloy A-286 sheet/plate. According to different production processes, Incoloy A-286 coils are divided into Incoloy A-286 hot rolled coils and Incoloy A-286 cold rolled coils. After they are flattened, they can be made into plate and sheet. The default finish of Incoloy A-286 cold rolled coil is 2B finish and the default finish of Incoloy A-286 hot rolled coil is No.1 finish. If you need other finish, please confirm with us to customize.
Customized Dimensions
Tolerance according to ASTM B906
*Customized size please confirm with us
Standards for Incoloy A-286 Coil
*We will strictly produce Incoloy A-286 Seamless Pipe & Tube according to the standard
Surface to be Customized
Chemical Composition of Incoloy A-286
*Chemical Composition According to SAE AMS 5525
Data Sheet
Physical Properties
| Density | g/cm3 | 7.94 | |
|---|---|---|---|
| lb/in.3 | 0.287 | ||
| Melting Range | °F | 2500 - 2600 | |
| °C | 1370 - 1430 | ||
Mechanical Properties
| Condition & Size | Tensile Strength | Yield Strength (0.2% Offset) | Elongation | Reduction of Area | Hardness |
|---|---|---|---|---|---|
| MPa, min | MPa, min | %, min | %, min | Rockwell | |
| Solution Treated / 0.025 to 0.038mm, incl | 724 | ... | 10 | ... | 90B max |
| Solution Treated / Over 0.038 to 0.05mm, incl | 724 | ... | 12 | ... | 90B max |
| Solution Treated / Over 0.05 to 0.10mm, incl | 724 | ... | 20 | ... | 90B max |
| Solution Treated / Over 0.10mm | 724 | ... | 25 | ... | 90B max |
| Aging Treated / 0.025 to 0.038mm, incl | 862 | 655 | 4 | ... | 24C to 35C |
| Aging Treated / Over 0.038 to 0.05mm, incl | 896 | 655 | 8 | ... | 24C to 35C |
| Aging Treated / Over 0.05 to 0.10mm, incl | 931 | 655 | 10 | ... | 24C to 35C |
| Aging Treated / Over 0.10mm | 965 | 655 | 15 | ... | 24C to 35C |
*Mechanical Properties According to SAE AMS 5525
