Hastelloy N (ERNiMo-2) Filler Metal Supplier
As a professional nickel alloy supplier, we manufacture high quality Hastelloy N (AWS A5.14 ERNiMo-2) filler Metal.
The nominal composition (wt %) of filler metal of Hastelloy N is 71 Ni, 16 Mo, 7 Cr, and 3 Fe. Filler metal of Hastelloy N is used for welding nickel-molybdenum alloy (ASTM B366, B434, and B573 having UNS number N10003) to itself, to steel, to other nickel-base alloys, and for cladding steel with nickel-molybdenum weld metal using the GTAW and GMAW processes.
Customized Dimensions
Tolerance: +0.01mm / -0.04mm
Tolerance: +0.01mm / -0.07mm
*Customized size please confirm with us
Standard for Hastelloy N Filler Metal
*We will strictly produce the Hastelloy N filler metal according to AWS A5.14.
Two Forms
Chemical Composition of Hastelloy N
*Chemical Composition According to AWS A5.14
ERNiMo-2 filler metal has lower requirements on chemical composition than general Hastelloy N materials. So you don't have to worry about the chemical composition of the material.
Data Sheet
Physical Properties
| Density | g/cm3 | 8.86 | |
|---|---|---|---|
| lb/in.3 | 0.32 | ||
| Melting Range | °F | 2375 - 2550 | |
| °C | 1300 - 1400 | ||
Mechanical Properties
| Condition & Size | Tensile Strength | Yield Strength (0.2% Offset) | Elongation | Reduction of Area | Hardness |
|---|---|---|---|---|---|
| MPa, min | MPa, min | %, min | %, min | Rockwell, max | |
| All | 690 | ... | ... | ... | ... |
*Mechanical Properties According to AWS A5.14
Hastelloy N Applications
Other Informations
Package
Plastic Spool
Plastic Box
Carton Box
Wooden Case
