Hastelloy B-3 (ERNiMo-10) Filler Metal Supplier
As a professional nickel alloy supplier, we manufacture high quality Hastelloy B-3 (AWS A5.14 ERNiMo-10) filler Metal.
The nominal composition (wt %) of filler metal of Hastelloy B-3 is 68 Ni, 28.5 Mo, 1.5 Cr, 1.5 Fe, and low carbon. Filler metal of Hastelloy B-3 is used for welding nickel-molybdenum alloy (ASTM B333, B335, B366, B564, B619, B622, and B626 having UNS number N10675) to itself, for welding the clad side of joints in steel clad with nickel-molybdenum alloy, and for welding nickel-molybdenum alloys to steel and to other nickel-base alloys using the GTAW, GMAW, and PAW processes.
Customized Dimensions
Tolerance: +0.01mm / -0.04mm
Tolerance: +0.01mm / -0.07mm
*Customized size please confirm with us
Standard for Hastelloy B-3 Filler Metal
*We will strictly produce the Hastelloy B-3 filler metal according to AWS A5.14.
Two Forms
Chemical Composition of Hastelloy B-3
*Chemical Composition According to AWS A5.14
The chemical composition of ERNiMo-10 is basically the same as the general Hastelloy B-3 alloy. But it removes the requirement for zirconium content.
Data Sheet
Physical Properties
| Density | g/cm3 | 9.22 | |
|---|---|---|---|
| lb/in.3 | 0.333 | ||
| Melting Range | °F | 2500 - 2585 | |
| °C | 1370 - 1418 | ||
Mechanical Properties
| Condition & Size | Tensile Strength | Yield Strength (0.2% Offset) | Elongation | Reduction of Area | Hardness |
|---|---|---|---|---|---|
| MPa, min | MPa, min | %, min | %, min | Rockwell, max | |
| All | 760 | ... | ... | ... | ... |
*Mechanical Properties According to AWS A5.14
Hastelloy B-3 Applications
Other Informations
Package
Plastic Spool
Plastic Box
Carton Box
Wooden Case
